Technical datas

Sensor type:  PTC Screw in sensor
Max. operation voltage:  30V
Nominal response temperature:  110°C
Tolerance of Eta_NRT:  ±5K
Reproductibility of Eta_NRT:  ±0.5K
Initial resistance R_25:  <100Ω
Resistance at a thermistor temperature of Eta_NRT -5K:  <550Ω
Resistance at a thermistor temperature of Eta_NRT +5K:  >1330Ω
Resistance at a thermistor temperature of Eta_NRT +15K:  >4kΩ
Insulation test voltage U_is AC:  1.5kV
Max. operating temperature:  180°C
Top bearing temperature:  60°C
Bottom bearing temperature:  -25°C
Protection class acc. To EN 60529:  IP65
Max. output pressure:  46bar
